Section 13 I/O Ports

Rev. 2.00 Sep. 24, 2008 Page 623 of 1468

REJ09B0412-0200

(2)

P64/TMCI3/

TEND3/ETEND1-B/TDI

The pin function is switched as shown below according to the combination of the EXDMAC and

DMAC register settings and P64DDR bit setting.

Setting

EXDMAC

DMAC

I/O Port

Module Name

Pin Function

MCU

Operation

Mode

ETEND1B_OE

TEND3_OE

P64DDR

EXDMAC

ETEND1-B output



DMAC

TEND3 output



P64 output

I/O port

P64 input

(initial value)

Except for

boundary scan

enabled mode*

Note:

These pins are boundary scan dedicated input pins during boundary scan enabled

mode.

(3)

P63/TMRI3/

DREQ3/EDREQ1-B/IRQ11-B/TMS

The pin function is switched as shown below according to the P63DDR bit setting.

Setting

I/O Port

Module Name

Pin Function

MCU Operation Mode

P63DDR

I/O port

P63 output

P63 input

(initial value)

Except for boundary scan

enabled mode*

Note:

These pins are boundary scan dedicated input pins during boundary scan enabled

mode.
