ADP3416JR Datenblatt (PDF) - Analog Devices

ADP3416JR Datasheet PDF - Analog Devices
Teilenummer ADP3416JR
Download  ADP3416JR Download
Filegröße   140.25 Kbytes
Page   8 Pages
Hersteller  AD [Analog Devices]
Direct Link  http://www.analog.com
Logo AD - Analog Devices
Bauteilbeschribung Dual Bootstrapped MOSFET Driver

ADP3416JR Datasheet (PDF)

Go To PDF Page Download Datenblatt
ADP3416JR Datasheet PDF - Analog Devices

Teilenummer ADP3416JR
Download  ADP3416JR Click to download

Filegröße   140.25 Kbytes
Page   8 Pages
Hersteller  AD [Analog Devices]
Direct Link  http://www.analog.com
Logo AD - Analog Devices
Bauteilbeschribung Dual Bootstrapped MOSFET Driver

ADP3416JR Datenblatt (HTML) - Analog Devices


ADP3416JR Produktdetails

GENERAL DESCRIPTION
The ADP3416 is a dual MOSFET driver optimized for driving two N-channel MOSFETs which are the two switches in a nonisolated synchronous buck power converter. One of the drivers can be bootstrapped and is designed to handle the high voltage slew rate associated with “floating” high side gate drivers. The ADP3416 includes overlapping drive protection (ODP) to prevent shoot-through current in the external MOSFETs.
The ADP3416 is specified over the commercial temperature range of 0°C to 70°C and is available in an 8-lead SOIC package.

FEATURES
   All-In-One Synchronous Buck Driver
   Bootstrapped High Side Drive
   One PWM Signal Generates Both Drives
   Anticross-Conduction Protection Circuitry
   Pulse-by-Pulse Disable Control

APPLICATIONS
   Mobile Computing CPU Core Power Converters
   Multiphase Desktop CPU Supplies
   Single-Supply Synchronous Buck Converters
   Standard-to-Synchronous Converter Adaptations
