AP2129K-1.2TRG1 Datenblatt (PDF) - BCD Semiconductor Manufacturing Limited
AP2129K-1.2TRG1 Datasheet PDF - BCD Semiconductor Manufacturing Limited
Teilenummer AP2129K-1.2TRG1
Download  AP2129K-1.2TRG1 Download
Filegröße   516.52 Kbytes
Page   15 Pages
Hersteller  BCDSEMI [BCD Semiconductor Manufacturing Limited]
Direct Link  http://www.bcdsemi.com
Logo BCDSEMI - BCD Semiconductor Manufacturing Limited
Bauteilbeschribung 300mA HIGH SPEED, EXTREMELY LOW NOISE CMOS LDO REGULATOR

AP2129K-1.2TRG1 Datasheet (PDF)

Go To PDF Page Download Datenblatt
AP2129K-1.2TRG1 Datasheet PDF - BCD Semiconductor Manufacturing Limited

Teilenummer AP2129K-1.2TRG1
Download  AP2129K-1.2TRG1 Click to download

Filegröße   516.52 Kbytes
Page   15 Pages
Hersteller  BCDSEMI [BCD Semiconductor Manufacturing Limited]
Direct Link  http://www.bcdsemi.com
Logo BCDSEMI - BCD Semiconductor Manufacturing Limited
Bauteilbeschribung 300mA HIGH SPEED, EXTREMELY LOW NOISE CMOS LDO REGULATOR

AP2129K-1.2TRG1 Datenblatt (HTML) - BCD Semiconductor Manufacturing Limited


AP2129K-1.2TRG1 Produktdetails

General Description
The AP2129 is a 300mA, positive Voltage regulator ICs fabricated by CMOS process. The AP2129 provides two kinds of output voltage operation modes for setting the output voltage. Fixed output voltage mode senses the output voltage on VOUT, adjustable output voltage mode needs two resistors as a voltage divider

Features
• Wide Operating Voltage: 1.8V to 6V
• High Output Voltage Accuracy: ±2%
• High Ripple Rejection:
    65dB@ f=1kHz, 45dB@ f=10kHz
• Low Standby Current: 0.1µA
• Low Quiescent Current: 60µA Typical
• Low Output Noise: 60µVrms
• Short Current Limit: 50mA
• Over Temperature Protection
• Compatible with Low ESR Ceramic Capacitor:
    1µF for CIN and COUT
• Excellent Line/Load Regulation
• Soft Start Time: 50µs
• Auto Discharge Resistance: RDS(ON)=60Ω

Applications
• Datacom
• Notebook Computers
• Mother Board
