TECHNICAL DATA SHEET

The PEWCP1041 is a WR-42 crossguide waveguide coupler that operates in the frequency range of 18 to 26.5 GHz. This

Waveguide component has a typical VSWR of 1.05:1. These designs are made of painted copper alloy and incorporate a

cross wall configuration that result in a mid-band nominal coupling value of 20, 30, 40 or 50 dB. Common applications for this

component would be where power measurements are required within a system for measuring/sampling power or frequency

monitoring with minimal signal loss to the main transmission line. This WR-42 waveguide coupler uses standard UG-595/U

square cover flanges. Pasternack offers a complete family of waveguide Crossguide and Top wall couplers that are in-stock

and ship same day.

Features

• Crossguide Waveguide Coupler

•

40 dB Nominal Coupling Level

• 18 GHz to 26.5 GHz Frequency Range

•

Body and Flanges made of Copper Alloy

•

Low VSWR

Applications

•

Test Benches

• Radar

• Satellite

• Microwave Radio

•

Attenuation Measurements

• Power Measurements

•

Source Leveling

Description

Minimum

Typical

Maximum

Units

Frequency Range

18

26.5

GHz

Directivity

20

dB

Insertion Loss

0.1

dB

Main Line VSWR

1.05:1

Nominal Coupling Level

40

dB

.

Mechanical Specifications

Size

Length

2.5 in [63.5 mm]

Width/Dia.

2.5 in [63.5 mm]

.

Weight

0.25 lbs [113.4 g]

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: WR-42 40 dB Waveguide Crossguide Coupler, UG-595/U Square Cover Flange, 18 GHz to

26.5 GHz PEWCP1041

PEWCP1041

PEWCP1041 REV 1.0

WR-42 40 dB Waveguide Crossguide Coupler, UG-

595/U Square Cover Flange, 18 GHz to 26.5 GHz
