SMD Shielded Flat Wire Power Choke

15

ALLIED COMPONENTS INTERNATIONAL

949-356-1780

www.alliedcomponents.com

RoHS

03/29/2017

Pre-Heat: 160ºC ±10°C

Test Equipment

(L): HP4284A LCR meter

Resistance to Soldering Heat

Solder Heat Resistance: 260ºC ± 5ºC for 10±1 sec.

DCR: Milli-ohm meter

Temp: 85°C ± 2°C

Physical

Packaging: 1500pcs per 13 inch reel

Marking: EIA Inductance Code

All specifications subject to change without notice.

Allied

Part

Number

Inductance

(µH)

Irms

(A)

Test

Frequency

(KHz, 0.25V)

Tolerance

(±%)

DCR

(mΩ)

Max

24.0

21.0

18.0

16.5

16.0

12.0

9.5

8.5

6.0

5.0

4.5

3.0

2.3

2.0

Isat

(A)

Typ

PCSFW630

PCSFW630-R22M

PCSFW630-R33M

PCSFW630-R47M

PCSFW630-R56M

PCSFW630-R68M

PCSFW630-1R0M

PCSFW630-1R5M

PCSFW630-2R2M

PCSFW630-3R3M

PCSFW630-4R7M

PCSFW630-6R8M

PCSFW630-100M

PCSFW630-150M

PCSFW630-220M

PCSFW630-330M

0.22

0.33

0.47

0.56

0.68

1.0

1.5

2.2

3.3

4.7

6.8

10

15

22

33

20

100

3.0

3.5

4.1

4.5

5.3

7.4

12.1

15.0

22.0

33.0

48.0

67.0

115.0

200.0

310.0

34.0

25.0

20.0

18.0

17.0

15.0

14.0

10.0

9.5

6.5

6.0

5.5

4.5

3.0

2.5

100

A

B

C

D

E

F

G

H

6.6±0.20

2.8±0.2

1.6±0.3

3.5

7.0±0.3

3.0±0.3

2.35

3.7

Features

•Magnetically Shielded Construction

Electrical

Inductance Range: 0.22µH to 33µH

Tolerance: 20% over entire range

Operating Temp: -55ºC ~ +125ºC

•Ultra High Saturation Current up to 14A

Test Frequency: 100KHz, 0.25V

•Low DC Resistance

•Expanded operating temp range

•Suitable for pick and place

Storage Temp: -55ºC ~ +125ºC

Irms: Current at which The Temperature would

Rise by Approximately 40°C

Isat: Current at which The Inductance will Drop

by Approximately 30%

Under no condition should the part exceed 125°C

Dimensions: (mm)
