TIME (5µs/DIV)

2V/DIV

0.01/DIV

Figure 16. Settling Time (Falling)

TIME (5µs/DIV)

2V/DIV

0.01/DIV

Figure 17. Settling Time (Rising)

12

11

10

9

8

7

6

5

4

3

2

1

0

–40

–20

0

20

40

60

80

100

120

140

TEMPERATURE (°C)

Figure 18. Maximum Output Sink Current vs. Temperature

Per Channel

12

11

10

9

8

7

6

5

4

3

2

1

0

–40

–20

0

20

40

60

80

100

120

140

TEMPERATURE (°C)

Figure 19. Maximum Output Source Current vs. Temperature

Per Channel

5.0

3.5

3.6

3.7

3.8

3.9

4.0

4.1

4.2

4.3

4.4

4.5

4.6

4.7

4.8

4.9

07.5

7.0

6.5

6.0

5.5

5.0

4.5

4.0

3.5

3.0

2.5

2.0

1.5

1.0

0.5

OUTPUT SOURCE CURRENT (mA)

Figure 20. Output Voltage Range vs. Output Source Current

Per Channel

2.0

1.8

1.6

1.4

1.2

1.0

0.8

0.6

0.4

0.2

0

010

9

8

7

6

5

4

3

2

1

OUTPUT SINK CURRENT (mA)

Figure 21. Output Voltage Range from GND vs. Output Sink Current

Per Channel
