AD8264

Rev. B | Page 15 of 40

−90

−60

−50

−80

−70

−30

−40

VGAIN (V)

0.7

0.5

0.3

0.1

–0.1

–0.3

–0.5

–0.7

VGAx = 0.5V p-p

VGAx = 1V p-p

VGAx = 2V p-p

INPUT LIMITED

Figure 45. HD3 vs. Amplitude to VGAx

−90

−60

−50

−80

−70

−30

−40

VGAIN (V)

0.7

0.5

0.3

0.1

–0.1

–0.3

–0.5

–0.7

1MHz

10MHz

35MHz

Figure 46. HD2 vs. VGAIN vs. Frequency to Differential Output

VGAIN (V)

0.7

0.5

0.3

0.1

–0.1

–0.3

–0.5

–0.7

−90

−45

−30

−75

−60

−15

1MHz

10MHz

35MHz

Figure 47. HD3 vs. VGAIN vs. Frequency to Differential Output

VGAIN (V)

0.7

0.5

0.3

0.1

–0.1

–0.3

–0.5

–0.7

−90

−60

−50

−80

−70

−30

−40

VOUT = 0.5V p-p

VOUT = 1V p-p

VOUT = 2V p-p

Figure 48. HD2 vs. Amplitude to Differential Output

−90

−60

−50

−80

−70

VOUT = 0.5V p-p

VOUT = 1V p-p

VOUT = 2V p-p

−30

−40

VGAIN (V)

0.7

0.5

0.3

0.1

–0.1

–0.3

–0.5

–0.7

Figure 49. HD3 vs. Amplitude to Differential Output

10M

FREQUENCY (Hz)

100M

LOW TONE, f – 50kHz

HIGH TONE, f + 50kHz

−20

−40

−60

−80

−100

VOUT = 1V p-p

Figure 50. IMD3 vs. Frequency to VGAx
