L3060

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

3 of 5

www.unisonic.com.tw

QW-R125-037.C



ABSOLUTE MAXIMUM RATING

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

-0.3~40

V

Drain Voltage of the Internal Power Switch

-0.3~40

V

+0.3~(-6.0)

V

Logic Level Dimming Input

-0.3~6

V

Switch Output Current

0.6

A

Power Dissipation

0.2

W

ESD Susceptibility (Note 2)

ESD

2

KV

Operation Junction Temperature Range

-40~150

°C

Storage Temperature

-55~150

°C

Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

2. Human body model, 100pF capacitor discharged through a 1.5kΩ resistor.



RECOMMENDED OPERATING RANGE

PARAMETER

SYMBOL

RATINGS

UNIT

0~30

V

Operating Temperature

-40~+85

°C



THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient

300

℃/W
