ADG904/ADG904-R
Rev. 0 | Page 10 of 16
SPECTRUM
ANALYZER
VDD
10
µF
VDD
ADG904-R
RF2
RF1
RFC
GND
50
Ω
COMBINER
RF
SOURCE
RF
SOURCE
A0
A1
1 0F 4
DECODER
EN
Figure 24. IP3
SPECTRUM
ANALYZER
VDD
10
µF
VDD
ADG904-R
RF2
RF1
RFC
50
Ω
RF
SOURCE
VS
GND
A0
A1
1 0F 4
DECODER
EN
Figure 25. P-1 dB
