3

Technical Data

10446

Effective September 2015

FP0505R

High frequency, high current power inductors

www.eaton.com/elx

Packaging information (mm)

Supplied in tape and reel packaging, 1,000 parts per 13” diameter reel

Temperature rise vs. total loss

0

10

20

30

40

50

60

0.00

0.10

0.20

0.30

0.40

0.50

0.60

0.70

Total Loss (W)

FP0505R1

User Direction of feed

5.2

7.5

1.75

2.0

4.0

12.0

5.2

5.0

16.0

±0.3

1.5

dia

1.5

dia
