Model SWT6

BI Technologies Corporation

4200 Bonita Place, Fullerton, CA 92835 USA

Phone: 714 447 2345 Website: www.bitechnologies.com

July 30, 2008

page

1 of 5

BI technologies

Tactile Switches 6X6 mm

500K Actuations

RoHS Compliant

MODELS AVAILABLE

Side Actuation

SWT6-R

Top Actuation

SWT6-V

Top Actuation with Ground

SWT6-E

SMD Top Actuation

SWT6-M

ELECTRICAL

Contact Resistance

100 mΩ

Current Rating

DC 12V, 50 mA

Insulation Resistance

100 MΩ min

Dielectric Strength

AC 250V

ENVIRONMENTAL

Life, Mechanical

500K Actuations

Operating Temperature Range

-20

oC – 70oC.

Storage Temperature

-30

oC – 80oC

Shock

Mil-STD-202F, Method 213B Condition A

Vibration

Mil-STD-202F, Method 201A

Operating Force Range (refer to definition table below))

100 gf – 260 gf
