PHOENIX CONTACT Inc., USA

Page 1 / 5

http://www.phoenixcon.com

Jan 31, 2011

Extract from the online

catalog



MSTBV 2,5/14-G

Order No.: 1753673

The figure shows a 10-position version of the product

http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1753673





Header, Nominal current: 12 A, Rated voltage (III/2): 320 V, Number of

positions: 14, Pitch: 5 mm, Color: green, Metal surface: Sn, Assembly:

Soldering



Commercial data

GTIN (EAN)

4

017918

028497

sales group

E110

Pack

50 pcs.

Customs tariff

85366990

Catalog page information

Page 251 (CC-2009)

Product notes

WEEE/RoHS-compliant since:

01/01/2003

http://

www.download.phoenixcontact.com

Please note that the data given

here has been taken from the

online catalog. For comprehensive

information and data, please refer

to the user documentation. The

General Terms and Conditions of

Use apply to Internet downloads.

Technical data

Dimensions / positions

Length

8.6 mm

Pitch

5 mm

Dimension a

65 mm

Number of positions

14
