SCIM2512S4-R003 Datenblatt(PDF) 1 Page - Cyntec Co., Ltd. |
|
|
|||||||||||||||||||||||||||||
SCIM2512S4-R003 Datenblatt(HTML) 1 Page - Cyntec Co., Ltd. |
|
|
1 / 9 page  DOCUMENT : CYNP-199-035 Page : 1 REVISION : A1 Current Sensor Resistor SCIM2512S4 Series, Current Sensor Resistor (Lead / Halogen Free) Features / Applications : High power rating is up to 4W Welding construction; excellent long-term stability Industrial applications & Current Sensor Resistor Suited for mounting on DBC / IMS substrate RoHS compliant Electrical Specifications : Characteristics1 Feature Power Rating2 4 W Resistance Value 0.3 to 3 mΩ Temperature Coefficient of Resistance (25/125℃) From 50 ppm/℃ Operation Temperature Range -65℃~ +170℃ Resistance Tolerance 1% Maximum Working Voltage (V) ( P*R)1/2 1. For detail information refer to the table on page 3 P/N list 2. For resistors are operated at terminal temperature in excess of 70℃, the maximum load shall be derated in accordance with the following curve. Figure 1.：Power derating curve at terminal temperature |
