Product Characteristics

Absolute Maximum Ratings

Stresses above the maximum values listed here may cause permanent damage to the device.

Table 2

Parameter

Symbol Min.

Typ.

Max.

Unit Note / Test Condition

Supply voltage

-

-

24

V

-0.6

-

-

V

applies

Reverse current

-200

-

-

mA

t = max 4 h

Junction temperature

-40

-

190

°C

max 4 h, < 16.5 V

Magnetic flux density

-

-

250

mT

-

-

500

mT

Operating Range

The following operating conditions must not be exceeded in order to ensure correct operation.

Table 3

Parameter

Symbol Min.

Typ.

Max.

Unit Note / Test Condition

Supply voltage

5.2

-

20

V

TLE5045iC-R100

4.25

-

20

V

TLE5045iC-R050

Operating Temperature

-40

190

°C

Magnetic signal frequency

0.03

-

3000

Hz

Minimum differential magnetic

input signal amplitude,

magnetic encoder application

70

90

110

µT

99% criterium

Magnetic induction amplitude

at each GMR

sensing element

-25

-

25

mT

Dynamic and static

homogeneous external

disturbance fields

-2

2

mT

no unwanted pulses

TLE5045iC

Technical product description

1 Product Characteristics

Technical Product Description

4

Revision 1.0

2018-11-06
