background image
isc Website：www.iscsemi.cn
isc & iscsemi is registered trademark
1
isc Silicon NPN Power Transistor
ISCN244P
DESCRIPTION
·
Low Collector Saturation Voltage
: VCE(sat)= 0.3V(Max)@ IC=3A
·
Collector-Emitter Breakdown Voltage-
: V(BR)CEO= 80V (Min)
·
Good Linearity of hFE
·
Minimum Lot-to-Lot variations for robust device
performance and reliable operation
APPLICATIONS
·
Designed for use in humidifier , DC/DC converter and
general purpose applications
ABSOLUTE MAXIMUM RATINGS(Ta=25℃)
SYMBOL
PARAMETER
VALUE
UNIT
VCBO
Collector-Base Voltage
200
V
VCEO
Collector-Emitter Voltage
80
V
VEBO
Emitter-Base Voltage
8
V
IC
Collector Current-Continuous
7
A
ICM
Collector Current-Pulse
14
A
IB
Base Current-Continuous
3
A
PC
Collector Power Dissipation
@ TC=25℃
50
W
TJ
Junction Temperature
150
℃
Tstg
Storage Temperature Range
-55~150
℃
