MODEL: 10LCS

http://www.m-system.co.jp/

10LCS SPECIFICATIONS

ES-0835 Rev.6 Page 3/3

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

130 (5.12)

3 (.12)

51 (2.01)

2–4.3 (.17) dia.

MTG HOLE

TERMINAL COVER

7–M3.5 SCREW

8 (.31)

25 (.98)

1

2

3

5

6

7

8

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

+

–

Isolation

Low Drift

Amplifier

Output

Driver

OUTPUT

7

8

OUTPUT

POWER

Z

S

+

–

1

5

6

2

3

+

–

STRAIN

GAUGE

Low Drift

DC Volt.

Stabilizer

EXC.

Specifications are subject to change without notice.
