MODEL: 18BXU
http://www.m-system.co.jp/
18BXU SPECIFICATIONS
ES-1898 Rev.0 Page 2/2
MOUNTING REQUIREMENTS unit: mm (inch)
2–M4 SCREW
ANGLE BRACKET
CONNECTION DIAGRAM
1
2
3
5
6
7
8
FG
U(+)
V(−)
POWER
+
−
Ch.1 OUTPUT 1 or INPUT
−
+
−
Ch.2 OUTPUT 1 or INPUT
−
DIMENSIONS unit: mm (inch)
78 (3.07)
1
94.5 (3.72)
34.5 (1.36)
POWER UNIT
2
Specifications are subject to change without notice.
