background image
WeEn Semiconductors
ESDALDxxBC
ESD Protection Diodes Array
ESDALDxxBC
Product data sheet
All information provided in this document is subject to legal disclaimers.
© WeEn Semiconductors Co., Ltd. 2021. All rights reserved
09 March 2021
2 / 5
6. Characteristics
Tj = 25 °C unless otherwise specified.
Product type Reverse Stand
off Voltage
VR
(V)
Min.
Breakdown
Voltage VBR @
IT = 1 mA
(V)
Max.
Clamping
Voltage VC @
Ipp = 1 A
(V)
Max.
Clamping
Voltage VC @
Max Ipp
(V)
Max. Peak
Pulse current
Ipp
(A)
Maximum
Reverse
Leakage
IR @ VR
(μA)
Typ. Cj
(pF) @
0 V,
1 MHz
ESDALD03BC
3.3
4.5
8.5
20
20
1
0.8
ESDALD05BC
5.0
6.5
10
21
15
1
0.8
ESDALD08BC
8.0
8.5
12
25
15
1
0.8
ESDALD12BC
12
13.3
19
35
10
1
0.8
ESDALD15BC
15
16.5
24
45
8
1
0.8
ESDALD24BC
24
26
34
55
6
1
0.8
ESDALD36BC
36
38
55
70
3
1
0.8
