Data Sheet
ADRF6720
Figure 40. LO Input Return Loss vs. LO Frequency (fLO)
Figure 41. LO Output Return Loss vs. LO Frequency (fLO)
–20
–18
–16
–14
–12
–10
–8
–6
–4
–2
0
0.3
1.3
2.3
3.3
4.3
5.3
6.3
LO FREQUENCY (GHz)
–35
–30
–25
–20
–15
–10
–5
0
0.3
1.3
2.3
3.3
4.3
5.3
6.3
LO FREQUENCY (GHz)
Rev. 0 | Page 17 of 44
