MODEL: M1EXM-2

M1EXM-2 SPECIFICATIONS

ES-5983 Rev.2 Page 5/7

https://www.m-system.co.jp/

PARAMETER LIST

It is available to con gure or con rm settings shown below by using front button. Con guring or con rming with PC is

available when using M1E con gurator software (model: M1ECFG).

MODE

ITEM

SETTING PARAMETER

RANGE

UNIT

INITIAL VALUE

Ch1 Setting

01

Lockout setting

Lock / Unlock

–

Lock

12

Ch1 0 % input setting

–

–

–

13

Ch1 100 % input setting

–

–

–

14

Ch1 0 % input scaling

-99999 – 999999

–

0.00

15

Ch1 100 % input scaling

-99999 – 999999

–

100.00

16

Ch1 Input decimal point

No decimal point

The number of decimal places: 1 – 5

–

2 places of decimals

17

Ch1 Unit (INP Scaling)

Choose from 68 types*

–

%

18

Ch1 Output range

0 – 20 mA

-5 – +5 V

-10 – +10 V

–

0 – 20 mA

19

Ch1 0 % output setting

0.000 – 19.000

-5.000 – 4.750

-10.000 – 9.000

mA

V

V

4.000

20

Ch1 100 % output setting

1.000 – 20.000

-4.750 – 5.000

-9.000 – 10.000

mA

V

V

20.000

79

Ch1 Filter time constant

0 – 30

sec.

0

82

Ch1 Output Zero fine adjust

-5.000 – 5.000

%

0.000

83

Ch1 Output Span fine adjust

95.000 – 105.000

%

100.000

89

Ch1 Loop test

-5.00 – 105.00

%

Cancel

Ch2 Setting

112

Ch2 0 % input setting

–

–

–

113

Ch2 100 % input setting

–

–

–

114

Ch2 0 % input scaling

-99999 – 999999

–

0.00

115

Ch2 100 % input scaling

-99999 – 999999

–

100.00

116

Ch2 Input decimal point

No decimal point

The number of decimal places: 1 – 5

–

2 places of decimals

117

Ch2 Unit (INP Scaling)

Choose from 68 types*

–

%

118

Ch2 Output range

0 – 20 mA

-5 – +5 V

-10 – +10 V

–

0 – 20 mA

119

Ch2 0 % output setting

0.000 – 19.000

-5.000 – 4.750

-10.000 – 9.000

mA

V

V

4.000

120

Ch2 100 % output setting

1.000 – 20.000

-4.750 – 5.000

-9.000 – 10.000

mA

V

V

20.000

179

Ch2 Filter time constant

0 – 30

sec.

0

182

Ch2 Output Zero fine adjust

-5.000 – 5.000

%

0.000

183

Ch2 Output Span fine adjust

95.000 – 105.000

%

100.000

189

Ch2 Loop test

-5.00 – 105.00

%

Cancel

01

Lockout setting

Lock / Unlock

–

Lock
