4 sensing.honeywell.com
MICRO SWITCH Miniature Precision Limit Switches, 914CE Series
44 mm max.
[1.73 in max.]
25 mm
[0.98 in]
16 mm max.
[0.63 in max.]
40 mm max.
[1.57 in max.]
Max. free length
Operating
position (OP)
3 mm min.
[0.12 in min.]
8,0 mm
[0.31 in]
8,0 mm
[0.32 in]
7,6 mm
[0.30 in]
Pretravel (PT)
Overtravel (OT)
CABLE VERSION
TYPE
Q or Q2
TYPE
Q1
M12
thread
1/2 x 20 UNF
thread
Two (2) holes Ø 5.1 mm [Ø 0.2 in] dia. c/bore
10,2 mm dia x 6 mm deep [0.40 in dia x 0.24 in deep]
(Both sides - option “A” only)
15 mm
[0.59 in]
GENERAL DIMENSIONS • ALL SWITCHES
PRODUCT NOMENCLATURE
3
16
2
1
Top pin
plunger
Top roller
plunger, parallel
Top roller
plunger, perp.
Side
rotary
914CE
Switch Type
29
Actuator Type
Options1
P
G
A Side entry
Gold
contacts
Top
mounting
19
18 Top pin plunger
w/ boot seal
Top adjustable
pin plunger
29
31
28
27 Top pin plunger,
panel mount
Top roller
plunger, parallel
panel mount
Top roller
plunger, perp.
panel mount
Top roller
plunger, parallel
boot seal
66
55
Top roller
plunger, perp.
boot seal
Top ball bearing
plunger
914CE Series
Small Precision
Limit Switch
L1
Low temp.
-40 °C, cable
not for flexing
–
9
6
3 3 feet
6 feet
9 feet
12 12 feet
15 15 feet
3
Cable Length*
20
Coil
wobble
22
Manually oper.
nylon button
V
Viton® seals/
gasket
(side rotary and
booted sealed
plungers only)
Connectors*
Q2
Q1
Q
dc type
single keyway
ac type
two keyways
dc type
optional pin-out
Bottom exit is
standard.
NOTE: not all combinations of model codes are available.
Please contact your Honeywell provider/representative for assistance.
*Select “Cable Length” or “Connectors”.
1
More than one option may be permissible.
