Product data sheet

Specifications

NEMA Motor Starter, Type S,

nonreversing, Size 1P, 36A, 5 HP

at 230 VAC, 5 kA SCCR, 1 phase,

2 pole, melting alloy, 208 VAC coil,

open

8536SCO2V08

Product availability : Non-Stock - Not normally stocked in

distribution facility

Main

Product Type

Motor starter

Product Range

S

Starter Type

Non reversing

Complementary

NEMA Size

1P

Rated Current

36 A

Number of Poles

2P

Maximum Voltage Rating

600 V AC

Phase

1 phase

Type of Overload

Melting alloy 2

Horsepower Rating

5 HP 230 V AC

3 HP 115 V AC

SCCR

Circuit-breaker: 5 kA at 600 V AC

Fuse: 5 kA at 600 V AC

Coil Voltage

208 V AC 60 Hz

Control Circuit Type

Common control circuit

Control Units

No control units

Pilot Light

Without pilot light

Auxiliary Contacts

Without

Terminal Type

Screw clamp terminals

Height

6.81 in (172.96 mm)

Width

3.50 in (88.90 mm)

Depth

4.22 in (107.19 mm)

Environment

Enclosure Type

Not rated (open device)

Certiﬁcations

UL Listed

CSA

Jul 13, 2022

1
