Product data sheet

Specifications

NEMA Motor Starter, Type S,

nonreversing, Size 6, 540A, 400 HP

at 460 VAC, 3 phase, 3 pole, melting

alloy, 120 VAC coil, open

8536SHO2V02S

Product availability : Stock - Normally stocked in distribution

facility

Price* : 21,756.00 USD

Main

Product Type

Motor starter

Product Range

S

Starter Type

Non reversing

Complementary

NEMA Size

6

Rated Current

540 A

Number of Poles

3P

Maximum Voltage Rating

600 V AC

Phase

3 phase

Type of Overload

Melting alloy 3

Horsepower Rating

150 HP 200 V AC

200 HP 230 V AC

400 HP 460 V AC

400 HP 575 V AC

Coil Voltage

110 V AC 50 Hz

120 V AC 60 Hz

Control Circuit Type

Control circuit transformer

Control Units

No control units

Pilot Light

Without pilot light

Auxiliary Contacts

Without

Other Equipment

2 fuses (primary), 2 fuses (secondary)

Terminal Type

Screw clamp terminals

Height

28.06 in (712.72 mm)

Width

12.34 in (313.44 mm)

Depth

9.00 in (228.60 mm)

Environment

Enclosure Type

Not rated (open device)

Certifications

UL Listed

*  Price is “List Price” and may be subject to a trade discount – check with your local distributor or retailer for actual price.

Jul 13, 2022
