12

B

ES40-R

Sealed Sub-Miniature Rocker Switches

FEATURES

SPECIFICATIONS

MATERIALS

(A)

ER

4

R 2

2

C

A5 S

R

Actuator

Vertical support

Bracket

SP on-none-on

SP on-none-(on)

SP on-off-on

SP (on)-off-(on)

SP on-off-(on)

DP on-none-on

DP on-none-(on)

DP on-off-on

DP (on)-off-(on)

DP on-off-(on)

Contact Material

1. Sealed construction - internal actuator o-ring and epoxy terminal seal standard

2. IP67 protection Degree

CONTACT RATING:R- 0.4 VA max @ 20 V AC or DC

ELECTRICAL LIFE:30,000 make-and-break cycles at full load

CONTACT RESISTANCE: 20 m max. initial @2-4 VDC,100 mA

INSULATION RESISTANCE: 1,000 M min.

DIELECTRIC STRENGTH: 1,500 V RMS @ sea level.

DEGREE OF PROTECTION : IP67

OPERATING TEMPERATURE: -30 Cto85 C

CASE and BUSHING - glass filled nylon ,6/6 flame retardant heat stabilized (UL94V-0 )

Actuator - Nylon,black standard. Internal o-ring seal standard with all actuator.

CONTACT AND TERMINAL - Copper alloy , gold plated

SWITCH SUPPORT - Brass , tin-lead

TERMINAL SEAL - Epoxy

How do you build the switches you need!!

The ER-4 / ER-5 , please see the (A) ;

The ER-6/ER-7/ER-8/ER-9, please see the (B)

ER-4

ER-4B

ER-4A

ER-4H

ER-4I

ER-5

ER-5B

ER-5A

ER-5H

ER-5I

Switches Function

R1

R2

Std.

7.62

Std.

5.84

Actuator Color

Termination

(none)

A5S

(std.) snap-in type

A5

straight type

(A)

ES

6

R 2

2

R

S

Actuator

Contact Material

Actuator

R1

R2

Std.

7.62

Std.

5.84

Actuator Color

Horizon Right

Angle

ER-6

ER-6B

ER-6A

ER-6H

ER-6I

ER-7

ER-7B

ER-7A

ER-7H

ER-7I

ER-8

ER-8B

ER-8A

ER-8H

ER-8I

ER-9

ER-9B

ER-9A

ER-9H

ER-9I

Switches Function

Vertical Right

Angle

SP on-none-on

SP on-none-(on)

SP on-off-on

SP (on)-off-(on)

SP on-off-(on)

DP on-none-on

DP on-none-(on)

DP on-off-on

DP (on)-off-(on)

DP on-off-(on)

Support Bracket

S

(std.) snap-in type

DB LECTRO Inc. 3600 boul. Matte suite i Brossard Qc J4Y-2Z2 tel:(450)-444-1424 fax:(450)-444-4714

DB LECTRO Inc.
