background image
CC2550
PRELIMINARY Data Sheet (Rev.1.2)
SWRS039A
Page 47 of 54
0x35 (0xF5): MARCSTATE – Main Radio Control State Machine state
Bit
Field Name
Reset
R/W
Description
7:5
Reserved
R0
4:0
MARC_STATE[4:0]
R
Main Radio Control FSM State
Value
State name
State (Figure 13, page 23)
0 (0x00)
SLEEP
SLEEP
1 (0x01)
IDLE
IDLE
2 (0x02)
XOFF
XOFF
3 (0x03)
VCOON_MC
MANCAL
4 (0x04)
REGON_MC
MANCAL
5 (0x05)
MANCAL
MANCAL
6 (0x06)
VCOON
FS_WAKEUP
7 (0x07)
REGON
FS_WAKEUP
8 (0x08)
STARTCAL
CALIBRATE
9 (0x09)
BWBOOST
SETTLING
10 (0x0A)
FS_LOCK
SETTLING
11 (0x0B)
IFADCON
SETTLING
12 (0x0C)
ENDCAL
CALIBRATE
13 (0x0D)
NA
NA
14 (0x0E)
NA
NA
15 (0x0F)
NA
NA
16 (0x10)
NA
NA
17 (0x11)
NA
NA
18 (0x12)
FSTXON
FSTXON
19 (0x13)
TX
TX
20 (0x14)
TX_END
TX
21 (0x15)
NA
NA
22 (0x16)
TX_UNDERFLOW
TX_UNDERFLOW
0x38 (0xF8): PKTSTATUS – Current GDOx status
Bit
Field Name
Reset
R/W
Description
7:2
Reserved
R0
Defined on the transceiver version
1
Reserved
R0
0
GDO0
R
Current GDO0 value. Note: the reading gives the non-
inverted value irrespective what IOCFG0.GDO0_INV is
programmed to.
It is not recommended to check for PLL lock by reading
PKTSTATUS[0]
with GDO0_CFG = 0x0A.
