NTV Series

3kVDC Isolated 1W Dual Output SM DC-DC Converters

KDC_NTV.L01 Page 1 of 7

www.murata.com

For full details go to

https://www.murata.com/en-

global/products/power/rohs

www.murata.com

SELECTION GUIDE

Order Code1

Nominal

Input

Voltage

Output

Voltage

Output

Current

Input

Current at

Rated Load

Efficiency

Isolation

Capacitance

MTTF2

V

V

mA

mA

%

pF

kHrs

NTV0505MC

5

±5

±100

282

71

33

1697

NTV0509MC

5

±9

±55

260

77

38

682

NTV0515MC

5

±15

±33

250

80

43

188

NTV1212MC

12

±12

±42

104

80

89

243

NTV1215MC

12

±15

±33

101

82

100

154

NTV0512MC

5

±12

±42

253

79

44

343

NKA0512SC

NTV1205MC

12

±5

±100

114

73

50

559

NKA1205SC

NTV1209MC

12

±9

±55

105

79

72

375

MEJ1D1209SC

When operated with additional external load capacitance the rise time of the input voltage will determine the maximum external

capacitance value for guaranteed start up. The slower the rise time of the input voltage the greater the maximum value of the

additional external capacitance for reliable start up.

PRODUCT OVERVIEW

The NTV series of 3kV isolation miniature

surface mounted DC-DC converters employ

leadframe technology and transfer mould-

ing techniques to bring all of the benefits of

IC style packaging to hybrid circuitry. The

co-planarity of the pin positions is based upon

IEC 191-6:1990. The devices are suitable for all

applications where high volume production is

envisaged.

FEATURES

RoHS compliant

Efficiency up to 82%

Wide temperature performance at full

1 Watt load, –40°C to 85°C

UL 94V-0 package material

Footprint over pins 1.64cm2

Lead frame technology

Dual isolated output

5V & 12V inputs

5V, 9V, 12V & 15V outputs

Internal SMD construction

Toroidal magnetics

Plastic encapsulated

3kVDC isolation (1 minute)

MTTF up to 1.7 million hours

Power density 1.36W/cm3

No heatsink required

Custom solutions available

Multi layer ceramic capacitors

INPUT CHARACTERISTICS

Parameter

Conditions

Min.

Typ.

Max.

Units

Voltage range

Continuous operation, 5V input types

4.5

5

5.5

V

Continuous operation, 12V input types

10.8

12

13.2

Reflected ripple current

41

47

mA p-p

1. If components are required in tape and reel format suffix order code code with -R, e.g. NTV0505MC-R.

2. Calculated using MIL-HDBK-217F with nominal input voltage at full load.

3. 12V input types have typically 3% less load regulation change.

All specifications typical at TA=25°C, nominal input voltage and rated output current unless otherwise specified.

OUTPUT CHARACTERISTICS

Parameter

Conditions

Min.

Typ.

Max.

Units

Rated Power

TA=-40°C to 85°C

1.0

W

Voltage Set Point Accuracy

See tolerance envelope

Line regulation

High VIN to low VIN

1.0

1.2

%/%

Load Regulation3

10% load to rated load, 5V output types

10

12

%

10% load to rated load, 9V output types

6.5

8.0

10% load to rated load, 12V output types

6.0

8.5

10% load to rated load, 15V output types

6.0

7.0

Ripple and Noise

BW=DC to 20MHz, 5V output types

50

75

mV p-p

BW=DC to 20MHz, 9V output types

40

65

BW=DC to 20MHz, 12V output types

40

60

BW=DC to 20MHz, 15V output types

40

60

ISOLATION CHARACTERISTICS

Parameter

Conditions

Min.

Typ.

Max.

Units

Isolation test voltage

Flash tested for 1 minute

3000

VDC

Resistance

Viso= 1000VDC

10

GΩ

GENERAL CHARACTERISTICS

Parameter

Conditions

Min.

Typ.

Max.

Units

Switching frequency

5V input types

115

kHz

12V input types

120
