B65819-J-R49 datasheet(1/6 Pages) EPCOS

Teilenummer	B65819-J-R49

Bauteilbeschribung	RM cores are supplied in sets

PDF	6 Pages

Scroll/Zoom	100%

Hersteller	EPCOS [EPCOS]

Direct Link	http://www.epcos.com

Logo

1 / 6 page

216 08/01

I In accordance with IEC 60431

I Core without center hole

for transformer applications

I RM cores are supplied in sets

Magnetic characteristics (per set)

Approx. weight (per set)

Gapped

with

center hole

without

center hole

Σl/A

le

Ae

Amin

Ve

0,74

29,8

40



1 200

0,7

30,4

43

39

1 340

mm–1

mm

mm2

mm3

m

6,5

7,2

g

Material

AL value

nH

s

approx.

mm

µe

Ordering code1)

-A with center hole

-N with threaded sleeve

-J without center hole

N41

160

± 5 %

0,30

89

B65819-J160-J41

250

± 5 %

0,18

139

B65819-J250-J41

N48

250

± 3 %

0,16

147

B65819-+250-A48

315

± 3 %

0,12

186

B65819-+315-A48

1) Replace the + by the code letter “A” or “N” for the required version.

B65819

Core

RM 7
