OUTLINE DIMENSIONS

3.04

2.90

2.80

PIN 1

1.40

1.30

1.20

2.64

2.10

1.90 BSC

1

2

3

SEATING

PLANE

1.12

0.89

0.10

0.01

0.50

0.30

0.20

0.08

0.60

0.50

0.40

0.95 BSC

COMPLIANT TO JEDEC STANDARDS TO-236-AB

Figure 26. 3-Lead Small Outline Transistor Package [SOT-23-3]

(RT-3)

Dimensions shown in millimeters

20.20

MIN

1.00 MIN

0.75 MIN

1.10

1.00

0.90

1.50 MIN

7” REEL 100.00

OR

13” REEL 330.00

7” REEL 50.00 MIN

OR

13” REEL 100.00 MIN

DIRECTION OF UNREELING

0.35

0.30

0.25

2.80

2.70

2.60

1.55

1.50

1.45

4.10

4.00

3.90

1.10

1.00

0.90

2.05

2.00

1.95

8.30

8.00

7.70

3.20

3.10

2.90

3.55

3.50

3.45

13.20

13.00

12.80

14.40 MIN

9.90

8.40

6.90

Figure 27. Tape and Reel Dimensions

(RT-3)

Dimensions shown in millimeters
