Low Profile Wideband Rail Antenna

Rail Antenna

3

*Gain is ground plane dependent; more gain can be achieved with larger ground plane.

** Specified height is height above mounting surface.

SPECIFICATIONS

Standard Configuration

Electrical Specifications – Band Specific

Model

Dimensions (L x H)

Temperature Range

Antenna Material

PCT-RSA-160

15.78 L x 4.32 H in (40.08 x 10.9 cm)

-40°C to +85°C

Aluminum, black hard coat anodized

PCT-RSA-220

6.81 L x 4.32 H in (17.2 x 10.9 cm)**

Model

Cable

Connector

Mount

PCT-RSA-160

Sold separately

Type N Female

Through-hole stud mounting for 1-inch holes

PCT-RSA-220

Model

Frequency Range

Gain*

VSWR

Average

Power

Nominal

Impedance

Polarization

PCT-RSA-160

158-163 MHz

2 dBi

< 1.5:1

100 watts

50 ohms

Vertical, linear

PCT-RSA-220

217-223 MHz

Mechanical and Environmental Specifications
