ORDERING INFORMATION

PACKING LIST

OPTIONAL ITEMS

• 1 ADS101/ADS103 motherboard

• 1 Serial ATA data & power cable w/lock

(Length: 300mm)

A81-002101-016G

• 1 COM port cable (Length: 250mm, 1 x COM port)

A81-015011-001G

• 1 I/O shield

- w/ icon (3LAN/4USB)

- w/ icon (2LAN/6USB)

A49-ADS101-000G

A49-ADS101-010G

• COM port cable (Length: 250mm, 1 x COM ports)

A81-015011-001G

• USB 3.1 cable (2-port USB3.1 Gen1/2, Length:

300mm, w/bracket)

A81-001075-017G

• Serial ATA data & power cable w/lock (Length:

300mm)

A81-002101-016G

• Thermal solution (For 35W, Height: 29.4mm)

A71-101136-000G

• Thermal solution (For 65W, Height: 46mm)

A71-101137-000G

• DT122 Chassis

761-DT1220-200G

• EXT-VGA module board

770-DP2VGA-000G

• EXT-HDMI module board

770-DP2HDM-000G

• EXT-DP module board

770-EXTDP1-000G

Model Name

P/N

Memory

Rear I/O

Internal I/O

TPM

Power

Operating

Temp.

Display

LAN

USB

M.2

USB

ADS101-R680DB 770-ADS1011-000G

2 DDR4

1 DP++,

1 DP++/HDMI

2

6 USB 3.2 Gen2

M.2 M/B/E Key

2 USB 3.2 Gen1,

4 USB 2.0

dTPM

12V

DC-IN

-5°C ~ 65°C

ADS101-Q670DB 770-ADS1011-100G

2

6 USB 3.2 Gen2

2 USB 3.2 Gen1,

4 USB 2.0

12V

DC-IN

ADS101-H610IB 770-ADS1011-200G

3

2 USB 3.2 Gen2,

1 USB 3.2 Gen1,

1 USB 2.0

4 USB 2.0

12V

DC-IN

ADS101-R680IB 770-ADS1011-300G

3

4 USB 3.2 Gen2

2 USB 3.2 Gen1,

4 USB 2.0

12V

DC-IN

ADS103-R680DB 770-ADS1031-000G

2

6 USB 3.2 Gen2

2 USB 3.2 Gen1,

4 USB 2.0

15~36V

DC-IN

ADS103-Q670DB 770-ADS1031-100G

2

6 USB 3.2 Gen2

2 USB 3.2 Gen1,

4 USB 2.0

15~36V

DC-IN

ADS103-H610IB 770-ADS1031-200G

3

2 USB 3.2 Gen2,

1 USB 3.2 Gen1,

1 USB 2.0

4 USB 2.0

15~36V

DC-IN

ADS103-R680IB 770-ADS1031-300G

3

4 USB 3.2 Gen2

2 USB 3.2 Gen1,

4 USB 2.0

15~36V

DC-IN
