Model TMR42524INCC

page 2

Copyright © 2016 Pliant Technologies, LLC. All rights reserved. The Pliant™ word mark and the Pliant

“P” logo are trademarks of Pliant Technologies, LLC. The Tempest ® and SmartBoom ® word marks are

trademarks of CoachComm LLC. Any and all other trademark references within this document are

property of their respective owners.

Pliant Technologies, LLC

Tempest ®

205 Technology Parkway

Auburn, AL 36830 USA

www.plianttechnologies.com

Phone +1.334.321.1160

Toll-Free 1.844.475.4268 or 1.844.4PLIANT

Fax +1.334.321.1162

SYSTEM SPECIFICATIONS*

RF Frequency

2400 to 2480 MHz

RF Scheme

FHSS with TDMA

Effective Radiated Power

100mW using 2dBi antenna

Receiver Sensitivity

-93 dBm for 10-5 BER

Radio Certification

FCC Part 15.247, ETS 300 328 v1.8.1 rules (apply to model numbers ending in “EU” only**),

Canadian RSS-210, license free.

Transmission Range

1,000 ft. (304.8 m) under ideal conditions. 500 ft. to 900 ft. (152.4 m to 274.3 m) typical

Audio Dynamic Range

>94 dB

Audio Frequency Response

300Hz–3.8KHz with proprietary audio voice shaping

System Latency

Less than 50 ms direct

RoHS Compliant

Yes

BELTSTATION SPECIFICATIONS*

Intercom Audio Channels

4

Simultaneous Listen Paths

True Dual Listen

Headset Connector

4-pin male XLR

Microphone Type

Dynamic or Electret, auto-selected

LCD Display

102 × 80 pixels

Antenna

Internal +2 dBi patch

USB BeltStation Power Supply

Input 100–240 V, 0.3 A, 50–60 Hz; Output 5 V, 1.25 A

Battery Life, Rechargeable

Up to 9 hours

Battery Charge Time, Lithium-Polymer Battery

Under 3 hours

Optional Power

3 Standard AA alkaline cells

Battery Life, Alkaline Batteries

Approximately 4 Hours

Dimensions

H 6.1 in. × W 4.0 in. × D 1.75 in. (156 mm × 102 mm × 44.5 mm)

Weight (with Lithium-Polymer Battery)

14.3 oz (405 g)

Operating Environment

-20° to 50° C (-4° to 122° F); 10% to 90% Humidity

TM24004CHBeltDataSheet_TMP-R424&EU_3.16

*Notice About Specifications

While Pliant makes every attempt to maintain the accuracy of the information contained in this

datasheet, this information is subject to change without notice. Please check our website for

the latest system specifications and certifications. Please check our website for the latest system

specifications and certifications.

**TMR42524INEU models meet the same specifications and comply with ETSI standards

(300.328 v1.8.1). Non-EU models are non-compliant with ETSI standards.
