I/O Table

(1) Two GbE ports are from independent Intel® Ethernet Controller I350-AM2 on RTM

(2) Supports VGA only when mated with cPCI-6930, cPCI-6880(P), cPCI-6870

(3) Converted from USB which unable to support Windows OS installation.

(4) Two onboard 7-pin signal connectors for external drives and one direct connector for onboard 2.5” SATA drive.

(5) Space is reserved onboard for one 2.5” SATA drive

Model

GbE

USB 2.0

COM

DVI

VGA

SATA

CF

PS/2 KB/MS

SD

cPCI-R6100 Faceplate

4(1)

4

1 (RJ-45)

1(2)

1

1

Onboard

2 (7-pin)

1(3)

1

cPCI-R6110 Faceplate

2

4

1

1

Onboard

3(4)(5)

1(3)

1

cPCI-R6120 Faceplate

2

4

1

1

Onboard

2 (4)(5)

(2.5” onboard)

1
