DS039-10
Sept ‘05
©2005 REG No 277 4001, ENGLAND.
Page 5
Antenna
SCTM4RA
The SCRTM4RA is a PCB mounting terminal providing a simple method of attaching a low cost 4mm Screw
thread antenna to a PCB.
PCB Layout
7.5
5
φ2DIA
A
A = 5,1mm excluding screw head, this also depends on how far the screw
terminal is from the outside surface of the box its fitted into.
All dimensions in mm
