Document Number: 001-84932 Rev. *N

Page 69 of 139

PSoC® 5LP: CY8C58LP Family

Datasheet

IDD[22]

Sleep Mode [23]

CPU = OFF

RTC = ON (= ECO32K ON, in low-power mode)

Sleep timer = ON (= ILO ON at 1 kHz)[24]

WDT = OFF

I2C Wake = OFF

Comparator = OFF

POR = ON

Boost = OFF

SIO pins in single ended input, unregulated output mode

VDD = VDDIO =

4.5–5.5 V

T = –40 °C

–

1.9

3.1

µA

T = 25 °C

–

2.4

3.6

T = 85 °C

–

T = 105 °C

–

VDD = VDDIO =

2.7–3.6 V

T = –40 °C

–

1.7

3.1

T = 25 °C

–

3.6

T = 85 °C

–

4.2

T = 105 °C

–

4.2

VDD = VDDIO =

1.71–1.95 V

T = –40 °C

–

1.6

3.1

T = 25 °C

–

1.9

3.6

T = 85 °C

–

4.2

T = 105 °C

–

4.2

Comparator = ON

CPU = OFF

RTC = OFF

Sleep timer = OFF

WDT = OFF

I2C Wake = OFF

POR = ON

Boost = OFF

SIO pins in single ended input, unregulated output mode

VDD = VDDIO =

2.7–3.6 V[25]

T = 25 °C

–

4.2

µA

I2C Wake = ON

CPU = OFF

RTC = OFF

Sleep timer = OFF

WDT = OFF

Comparator = OFF

POR = ON

Boost = OFF

SIO pins in single ended input, unregulated output mode

VDD = VDDIO =

2.7–3.6 V[25]

T = 25 °C

–

1.7

3.6

µA

Table 11-2. DC Specifications (continued)

Parameter

Description

Conditions

Min

Typ

Max

Units

Notes

22. The current consumption of additional peripherals that are implemented only in programmed logic blocks can be found in their respective datasheets, available in

PSoC Creator, the integrated design environment. To estimate total current, find CPU current at frequency of interest and add peripheral currents for your particular

system from the device datasheet and component datasheets.

23. If VCCD and VCCA are externally regulated, the voltage difference between VCCD and VCCA must be less than 50 mV.

24. Sleep timer generates periodic interrupts to wake up the CPU. This specification applies only to those times that the CPU is off.

25. Based on device characterization (Not production tested).
