For crimping tool information, see page D1.84 and D1.88.

Metric Ring Terminal, Vinyl Insulated – Funnel Entry

• Ring tongue design assures a secure connection in high

vibration applications

• Insulation support helps to prevent wire damage in

bending applications

• Brazed seam protects terminal barrel from splitting during the

crimp process

• Internal barrel serrations assure good wire contact and maximum

tensile strength

• Maximum insulation temperature 221°F (105°C)

• Rated up to 600 V

Type PMV-R

C

L

W

Part Number

Wire

Range

(mm2)

Color

Code

Max.

Ins.

(mm)

Stud

Size

Figure Dimensions

(mm)

Recommended

Installation

Tool

Std.

Pkg.

Qty.

Std.

Ctn.

Qty.

L

W

C

PMV1-3RB-CY

0.5 – 1.0

Red

4.01

M3

20.8

5.8

5.6

CT-1550,

CT-2500

100

500

PMV1-4RB-CY

4.01

M4

23.1

7.9

7.4

100

500

PMV1-5RB-CY

4.01

M5

23.1

8.9

7.4

100

500

PMV1-6RB-CY

4.01

M6

28.2

10.9

10.7

100

500

PMV2-3RB-C

1.5 – 2.5

Blue

4.70

M3

20.5

5.8

6.4

CT-1550,

CT-2500

100

500

PMV2-4RB-C

4.70

M4

23.1

7.9

6.4

100

500

PMV2-5RB-C

4.70

M5

23.8

8.9

6.4

100

500

PMV2-6RB-C

4.70

M6

25.7

10.9

9.7

100

500

PMV6-3R-L

4.0 – 6.0

Yellow

6.10

M3

26.1

5.8

7.9

CT-1550,

CT-2500

50

250

PMV6-4R-L

6.10

M4

26.5

7.9

7.9

50

250

PMV6-5R-L

6.10

M5

27.1

9.5

7.9

50

250

PMV6-6R-L

6.10

M6

30.3

10.9

9.7

50

250

PMV6-8R-L

6.10

M8

31.4

13.2

9.7

50

250

Metric Ring Terminal, Non-Insulated

• Ring tongue design assures a secure connection in high

vibration applications

• Internal barrel serrations assure good wire contact and maximum

tensile strength

• Brazed seam protects terminal barrel from splitting during the

crimp process

• Barrel of terminal internally beveled to provide quick and easy

wire insertion

• Maximum recommended operating temperature 302°F (150°C)

• Rated up to 2000 V

For crimping tool information, see pages D1.84 and D1.88.

Part Number

Wire

Range

(mm2)

Stud

Size

Figure Dimensions

(mm)

Recommended

Installation

Tool

Std.

Pkg.

Qty.

Std.

Ctn.

Qty.

L

W

C

PM1-3R-C

0.5 – 1.5

M3

15.8

5.8

5.6

CT-1570,

CT-2500

100

500

PM1-4R-C

M4

18.0

7.9

7.4

100

500

PM1-5R-C

M5

18.0

8.9

7.4

100

500

PM2-3R-C

1.0 – 2.5

M3

15.8

5.8

5.6

CT-1570,

CT-2500

100

500

PM2-4R-C

M4

18.0

7.9

7.4

100

500

PM2-5R-C

M5

18.0

8.9

7.4

100

500

PM6-3R-L

2.5 – 6.0

M3

19.2

5.8

7.9

CT-1570,

CT-2500

50

250

PM6-4R-L

M4

19.8

7.9

7.9

50

250

PM6-5R-L

M5

20.6

9.5

7.9

50

250

PM6-6R-L

M6

23.5

10.9

9.7

50

250

PM6-8R-L

M8

24.7

13.3

9.7

50

250

Type PM-R

C

L

W
