D

D

B

B

B

Military Grade Heat Shrink Labels

Standard package quantity is 1 roll.

*Available in bulk package (5 times Standard Package Quantity), add -B to end of part number (only available in certain sizes in white color).

A,C

A,C

D

A,C

H150X_ _ _H_T

H200X_ _ _H_T

H075X_ _ _H_T

H100X_ _ _H_T

H050X_ _ _H_T

© 2008

PANDUIT Corp.

ALL RIGHTS RESERVED.

Printed in the U.S.A.

SA-IDSP11

3/2008

WORLDWIDE SUBSIDIARIES AND SALES OFFICES

For a copy of

PANDUIT product warranties, log on to www.panduit.com/warranty

PANDUIT CANADA

Markham, Ontario

cs-cdn@panduit.com

Phone: 800.777.3300

PANDUIT EUROPE LTD.

London, UK

cs-emea@panduit.com

Phone: 44.20.8601.7200

PANDUIT JAPAN

Tokyo, Japan

cs-japan@panduit.com

Phone: 81.3.3767.7011

PANDUIT SINGAPORE PTE. LTD.

Republic of Singapore

cs-ap@panduit.com

Phone: 65.6305.7575

PANDUIT AUSTRALIA PTY. LTD.

Victoria, Australia

cs-aus@panduit.com

Phone: 61.3.9794.9020

PANDUIT LATIN AMERICA

Jalisco, Mexico

cs-la@panduit.com

Phone: 52.333.777.6000

Contact Customer Service by email: cs@panduit.com

or by phone: 800-777-3300 and reference IDSP11

Visit us at www.panduit.com

For more information

White Color

Part #

Yellow Color

Part #

Black Color

Part #

Red Color

Part #

Diameter

Width

'A'

Height

'B'

Horizontal

Repeat

'C'

Vertical

Repeat

'D'

Labels

per

Row

Labels

per Roll

Min. Cable

O.D.

Max. Cable

O.D.

Wire/

Cable

Size

H050X025H1T* H050X025H2T H050X025H3T H050X025H4T

1/8"

(3.1mm)

0.50"

(12.7mm)

0.25"

(6.4mm)

0.50"

(12.7mm)

1.00"

(25.4mm)

4

2000

0.04"

(1.0mm)

0.13"

(3.3mm)

22-18

AWG

H075X025H1T* H075X025H2T H075X025H3T H075X025H4T

1/8"

(3.1mm)

0.75"

(19.0mm)

0.25"

(6.4mm)

0.75"

(19.0mm)

1.00"

(25.4mm)

2

1000

0.04"

(1.0mm)

0.13"

(3.3mm)

H100X025H1T* H100X025H2T H100X025H3T H100X025H4T

1/8"

(3.1mm)

1.00"

(25.4mm)

0.25"

(6.4mm)

1.00"

(25.4mm)

1.00"

(25.4mm)

2

1000

0.04"

(1.0mm)

0.13"

(3.3mm)

H150X025H1T* H150X025H2T H150X025H3T H150X025H4T

1/8"

(3.1mm)

1.50"

(38.1mm)

0.25"

(6.4mm)

N/A

1.00"

(25.4mm)

1

500

0.04"

(1.0mm)

0.13"

(3.3mm)

H200X025H1T* H200X025H2T H200X025H3T H200X025H4T

1/8"

(3.1mm)

2.00"

(50.8mm)

0.25"

(6.4mm)

N/A

1.00"

(25.4mm)

1

500

0.04"

(1.0mm)

0.13"

(3.3mm)

H050X034H1T* H050X034H2T H050X034H3T H050X034H4T

3/16"

(4.7mm)

0.50"

(12.70mm)

0.34"

(8.6mm)

0.50"

(12.7mm)

1.00"

(25.4mm)

4

2000

0.06"

(1.5mm)

0.19"

(4.8mm)

18-12

AWG

H075X034H1T* H075X034H2T H075X034H3T H075X034H4T

3/16"

(4.7mm)

0.75"

(19.0mm)

0.34"

(8.6mm)

0.75"

(19.0mm)

1.00"

(25.4mm)

2

1000

0.06"

(1.5mm)

0.19"

(4.8mm)

H100X034H1T* H100X034H2T H100X034H3T H100X034H4T

3/16"

(4.7mm)

1.00"

(25.4mm)

0.34"

(8.6mm)

1.00"

(25.4mm)

1.00"

(25.4mm)

2

1000

0.06"

(1.5mm)

0.19"

(4.8mm)

H150X034H1T* H150X034H2T H150X034H3T H150X034H4T

3/16"

(4.7mm)

1.50"

(38.1mm)

0.34"

(8.6mm)

N/A

1.00"

(25.4mm)

1

500

0.06"

(1.5mm)

0.19"

(4.8mm)

H200X034H1T* H200X034H2T H200X034H3T H200X034H4T

3/16"

(4.7mm)

2.00"

(50.8mm)

0.34"

(8.6mm)

N/A

1.00"

(25.4mm)

1

500

0.06"

(1.5mm)

0.19"

(4.8mm)

H050X044H1T* H050X044H2T H050X044H3T H050X044H4T

1/4"

(6.3mm)

0.50"

(12.70mm)

0.44"

(11.1mm)

0.50"

(12.7mm)

1.00"

(25.4mm)

4

2000

0.08"

(2.0mm)

0.25"

(6.3mm)

16-10

AWG

H075X044H1T* H075X044H2T H075X044H3T H075X044H4T

1/4"

(6.3mm)

0.75"

(19.0mm)

0.44"

(11.1mm)

0.75"

(19.0mm)

1.00"

(25.4mm)

2

1000

0.08"

(2.0mm)

0.25"

(6.3mm)

H100X044H1T* H100X044H2T H100X044H3T H100X044H4T

1/4"

(6.3mm)

1.00"

(25.4mm)

0.44"

(11.1mm)

1.00"

(25.4mm)

1.00"

(25.4mm)

2

1000

0.08"

(2.0mm)

0.25"

(6.3mm)

H150X044H1T* H150X044H2T H150X044H3T H150X044H4T

1/4"

(6.3mm)

1.50"

(38.1mm)

0.44"

(11.1mm)

N/A

1.00"

(25.4mm)

1

500

0.08"

(2.0mm)

0.25"

(6.3mm)

H200X044H1T* H200X044H2T H200X044H3T H200X044H4T

1/4"

(6.3mm)

2.00"

(50.8mm)

0.44"

(11.1mm)

N/A

1.00"

(25.4mm)

1

500

0.08"

(2.0mm)

0.25"

(6.3mm)

H050X064H1T* H050X064H2T H050X064H3T H050X064H4T

3/8"

(9.5mm)

0.50"

(12.70mm)

0.64"

(16.2mm)

0.50"

(12.7mm)

1.50"

(38.1mm)

4

2000

0.16"

(4.0mm)

0.38"

(9.6mm)

12-6

AWG

H100X064H1T* H100X064H2T H100X064H3T H100X064H4T

3/8"

(9.5mm)

1.00"

(25.4mm)

0.64"

(16.2mm)

1.00"

(25.4mm)

1.50"

(38.1mm)

2

1000

0.16"

(4.0mm)

0.38"

(9.6mm)

H200X064H1T* H200X064H2T H200X064H3T H200X064H4T

3/8"

(9.5mm)

2.00"

(50.8mm)

0.64"

(16.2mm)

N/A

1.50"

(38.1mm)

1

500

0.16"

(4.0mm)

0.38"

(9.6mm)

H100X084H1T

H100X084H2T H100X084H3T H100X084H4T

1/2"

(12.7mm)

1.00"

(25.4mm)

0.84"

(21.3mm)

1.00"

(25.4mm)

1.50"

(38.1mm)

2

1000

0.17"

(4.3mm)

0.50"

(12.7mm)

8-1

AWG

H200X084H1T

H200X084H2T H200X084H3T H200X084H4T

1/2"

(12.7mm)

2.00"

(50.8mm)

0.84"

(21.3mm)

N/A

1.50"

(38.1mm)

1

500

0.17"

(4.3mm)

0.50"

(12.7mm)

H100X165H1T

H100X165H2T H100X165H3T H100X165H4T

1.00"

(25.4mm)

1.00"

(25.4mm)

1.65"

(41.9mm)

1.00"

(25.4mm)

2.50"

(63.5mm)

2

500

0.33"

(8.38mm)

1.00"

(25.4mm)

4 AWG

- 500

MCM

H200X165H1T

H200X165H2T H200X165H3T H200X165H4T

1.00"

(25.4mm)

2.00"

(50.8mm)

1.65"

(41.9mm)

N/A

2.50"

(63.5mm)

1

250

0.33"

(8.38mm)

1.00"

(25.4mm)
