STLED316S
Pin description
9/33
Pin number
Symbol
Type
Name and function
13,14,15,16
SEG8/KS8
to
SEG5/KS5
OUT
Segment output pins (dual function as key source).
17
GND
PWR
Connect this pin to system GND.
18,19,20,21
SEG4/KS4
to
SEG1/KS1
OUT
Segment output pins (dual function as key source).
22
KEY2
IN
Key 2 input. Input data to these pins from external
keyboard are latched at end of the display cycle
(maximum keyboard size is 8 x 2).
23
KEY1
IN
Key 1 input. Input data to these pins from external
keyboard are latched at end of the display cycle
(maximum keyboard size is 8 x 2).
24
ISET
IN
Segment current setting. Connect to GND through a
resistor to set the peak segment current.
Table 2.
Pin description (continued)
