Section 16 USB Function Module (USB)

Rev.1.00 Jun. 07, 2006 Page 787 of 1102

REJ09B0294-0100

Bit

Transfer

Mode

Interrupt

Source

Description

Interrupt

Request

Signal

DTC

Activation

DMAC

Activation

SETI

Set_Interface

command detection

USBINTN2 or

USBINTN3

Status

SETC

Set_Configuration

command detection

USBINTN2 or

USBINTN3

—

Reserved



—

IFR2

CFDN

Endpoint information

load end

USBINTN2 or

USBINTN3

Status

SURSF

Suspend/resume

detection

USBINTN2,

USBINTN3, or

RESUME

SURSS

Suspend/resume

status

—

Reserved

—

Note:

EP0 interrupts must be assigned to the same interrupt request signal.

• USBINTN0 signal

DMAC start interrupt signal only EP1. See section 16.8, DMA Transfer.

• USBINTN1 signal

DMAC start interrupt signal only EP1. See section 16.8, DMA Transfer.

• USBINTN2 signal

The USBINTN2 signal requests interrupt sources for which the corresponding bits in interrupt

select registers 0 to 2 (ISR0 to ISR2) are cleared to 0. The USBINTN2 is driven low if a

corresponding bit in the interrupt flag register is set to 1.

• USBINTN3 signal

The USBINTN3 signal requests interrupt sources for which the corresponding bits in interrupt

select registers 0 to 2 (ISR0 to ISR2) are cleared to 0. The USBINTN3 is driven low if a

corresponding bit in the interrupt flag register is set to 1.

• RESUME signal

The RESUME signal is a resume interrupt signal for canceling software standby mode. The

RESUME signal is driven low at the transition to the resume state for canceling software

standby mode.
