4. Description of Abbreviations

The abbreviations used in this manual are listed below.

• Abbreviations specific to this product

Abbreviation

Description

BSC

Bus controller

CPG

Clock pulse generator

DTC

Data transfer controller

INTC

Interrupt controller

PPG

Programmable pulse generator

SCI

Serial communications interface

TMR

8-bit timer

TPU

16-bit timer pulse unit

WDT

Watchdog timer

• Abbreviations other than those listed above

Abbreviation

Description

ACIA

Asynchronous communications interface adapter

bps

Bits per second

CRC

Cyclic redundancy check

DMA

Direct memory access

DMAC

Direct memory access controller

GSM

Global System for Mobile Communications

Hi-Z

High impedance

IEBus

Inter Equipment Bus (IEBus is a trademark of NEC Electronics Corporation.)

I/O

Input/output

IrDA

Infrared Data Association

LSB

Least significant bit

MSB

Most significant bit

No connection

PLL

Phase-locked loop

PWM

Pulse width modulation

SFR

Special function register

SIM

Subscriber Identity Module

UART

Universal asynchronous receiver/transmitter

VCO

Voltage-controlled oscillator
