28
1772E–DRMSD–10-Apr-06
ATSAM9708
24. Recommended Crystal Compensation and LFT Filter
Figure 24-1. Recommended Crystal Compensation and LFT Filter
X1
X2
LFT
RESET
PDWN
134
61
62
60
137
X1
C4
22 pF
C1
22 pF
C2
2.2 nF
R1
100
C3
10 nF
Ω
