MECHANICAL DATA
MPDI006B – SEPTEMBER 2001 – REVISED APRIL 2002
POST OFFICE BOX 655303
• DALLAS, TEXAS 75265
N (R–PDIP–T24)
PLASTIC DUAL–IN–LINE
0.020 (0,51) MIN
0.021 (0,53)
0.015 (0,38)
0.100 (2,54)
1
24
0.070 (1,78) MAX
12
13
1.222 (31,04) MAX
0.125 (3,18) MIN
0’–15’
0.010 (0,25) NOM
0.425 (10,80) MAX
Seating Plane
0.200 (5,08) MAX
0.360 (9,14) MAX
0.010 (0,25)
4040051–3/D 09/01
NOTES: A. All linear dimensions are in inches (millimeters).
B. This drawing is subject to change without notice.
C. Falls within JEDEC MS–010
