FREQUENCY

(MHz)

CONVERSION LOSS

(dB)

LO-RF ISOLATION

(dB)

LO-IF ISOLATION

(dB)

IP3

at center

band

(dBm)

LO/RF

IF

Mid-Band

m

Total

Range

Max.

L

M

U

L

M

U

f

—

X

σ

Max.

Typ. Min.

Typ. Min.

Typ. Min.

Typ. Min.

Typ. Min.

Typ. Min.

Typ.

0.2-250

DC-200

4.9

0.05

7.0

8.4

70 54

50 37

40 28

65 45

45 31

33 20

16

1 dB COMP.: +5 dBm typ.

L = low range [f

M = mid range [10 f

U = upper range [f

m= mid band [2f

ISO 9001 ISO 14001 CERTIFIED

P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site

The Design Engineers Search Engine Provides ACTUAL Data Instantly From MINI-CIRCUITS At: www.minicircuits.com

RF/IF MICROWAVE COMPONENTS

minicircuits.com

ALL NE

W

Page 1 of 2

Frequency

(MHz)

Conversion

Loss

(dB)

Isolation

L-R

(dB)

Isolation

L-I

(dB)

VSWR

RF Port

(:1)

VSWR

LO Port

(:1)

RF

LO

LO

+10dBm

LO

+10dBm

LO

+10dBm

LO

+10dBm

LO

+10dBm

Level 10 (LO Power +10 dBm) 0.2 to 250 MHz

High Reliability Mixer

Surface Mount

Maximum Ratings

Pin Connections

LO

6

RF

3

IF

2

GROUND

1,4,5

Electrical Specifications

REV. OR

M109914

ADE-R6LH+

ED-12873/8

WL/QL

070516

Typical Performance Data

Operating Temperature

-40°C to 85°C

Storage Temperature

-55°C to 100°C

RF Power

50mW

IF Current

40mA

Features

• hermetically sealed ceramic quad

• low conversion loss, 4.9 dB typ.

• excellent L-R isolation, 50 dB typ.

• low profile package

• aqueous washable

• protected by US Patent 6,133,525

Applications

• cellular

ADE-R6LH+

CASE STYLE: CD637

PRICE: $5.35 ea. QTY. (10-49)

+ RoHS compliant in accordance

with EU Directive (2002/95/EC)

The +Suffix has been added in order to identify RoHS

Compliance. See our web site for RoHS Compliance

methodologies and qualifications.

PCB Land Pattern

Suggested Layout,

Tolerance to be within ±.002

Demo Board MCL P/N: TB-03

Suggested PCB Layout (PL-052)

Outline Drawing

Outline Dimensions (

)

inch

mm

A

B

C

D

E

F

G

.272

.310

.220

.100

.206

.055

.100

6.91

7.87

5.59

2.54

5.23

1.40

2.54

H

J

K

L

wt

.030

.026

.065

.300

grams

0.76

0.66

1.65

7.62

0.40

Electrical Schematic

0.20

30.20

4.97

67.49

61.77

1.28

2.18

0.25

30.25

4.95

62.09

55.17

1.27

2.15

1.00

31.00

4.85

60.50

52.85

1.26

2.15

5.00

35.00

4.69

58.51

50.92

1.28

2.13

11.00

41.00

4.69

59.26

48.97

1.28

2.12

32.00

62.00

4.73

56.10

47.87

1.26

2.14

43.00

73.00

4.79

52.69

46.84

1.25

2.14

65.00

95.00

4.84

54.99

44.91

1.21

2.16

87.00

117.00

4.84

58.06

43.53

1.16

2.20

98.00

128.00

4.85

54.34

44.03

1.13

2.20

109.00

139.00

4.89

48.39

43.91

1.17

2.21

120.00

150.00

4.99

45.43

41.05

1.18

2.25

140.00

170.00

4.99

41.52

37.78

1.11

2.24

160.00

190.00

5.02

39.86

36.11

1.10

2.32

180.00

210.00

5.11

41.06

36.87

1.03

2.44

190.00

220.00

5.32

40.52

38.41

1.07

2.51

200.00

230.00

5.47

40.00

37.98

1.18

2.59

210.00

240.00

5.46

39.31

36.15

1.24

2.57

220.00

250.00

5.55

38.20

34.51

1.30

2.54

250.00

280.00

5.82

36.14

31.62

1.44

2.58
