ML74WLCF Datenblatt(PDF) 3 Page - Minilogic Device Corporation Limited

Teilenummer ML74WLCF
Bauteilbeschribung  Inverter (unbuffered) and Buffer
PDF  4 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Hersteller  MINILOGIC [Minilogic Device Corporation Limited]
Direct Link  http://www.minilogic.com.hk
Logo MINILOGIC - Minilogic Device Corporation Limited

ML74WLCF Datenblatt(HTML) 3 Page - Minilogic Device Corporation Limited

  ML74WLCF Datasheet HTML 1Page - Minilogic Device Corporation Limited ML74WLCF Datasheet HTML 2Page - Minilogic Device Corporation Limited ML74WLCF Datasheet HTML 3Page - Minilogic Device Corporation Limited ML74WLCF Datasheet HTML 4Page - Minilogic Device Corporation Limited
Zoom Inzoom in Zoom Outzoom out
 3 / 4 page
background image
Rev. B, Sep 2005
■
Noise Characteristics
(tr=tf=3ns)
Ta=25°°°°C
PARAMETER
SYMBOL
CL
Vcc(V)
CONDITIONS
MIN
TYP
MAX
UNITS
Not functioning output maximum
dynamic VOL
VOLP
50pF
5.0
--
0.3
0.8
V
Not functioning output minimum
dynamic VOL
VOLV
50pF
5.0
-0.8
-0.3
--
V
Minimum dynamic VIH
VIHD
50pF
5.0
--
--
3.5
V
Maximum dynamic VIL
VILD
50pF
5.0
--
--
1.5
V
■
Typical Application Circuit
Note: Open output when measuring supply current
■
