SPECIFICATIONS

Part numbers indicate tolerance available.

M = ±20%, N = ±30%

L Test

DCR

IDC

Part

Inductance

Freq.

Max.

Max.

Number

(µH)

(kHz)

(

Ω

Ω)

(A)

CTEPH149-R56N

0.56

100

0.0010

30

CTEPH149-1R0M

1.00

100

0.0012

22

CTEPH149-1R6M

1.60

100

0.0015

18

CTEPH149-2R2M

2.20

100

0.0019

15

CTEPH149-2R4M

2.40

100

0.0015

10

CTEPH149 Series

From 0.56 µH to 2.4 µH

Not shown at actual size.

CHARACTERISTICS

Description: SMD shielded power inductor (Ultra High Current)

Applications: Excellent for power line DC-DC conversion

applications used in notebook computers and other handheld

electronic equipment

Operating Temperature: -25°C to +85°C

Storage Temperature: -40°C to +105°C

Temperature rise: 40°C Typical at IDC

Resistance to solder heat: 260°C for 10 seconds

Rated Current: Based on temperature &

∆L / L0A =25% Typ. at

IDC

Inductance Tolerance: ±20%, ±30%

Testing: Tested on a HP4285A at 100 KHz , 1V

Packaging: Tape & Reel

Marking: Parts are marked with inductance code

Additional Information: Additional electrical & physical

information available upon request

Samples available. See website for ordering information.

PAD LAYOUT

5.0

Unit: mm

3.0

3.0

Marking

A

C

Inductance Code

D

H

G

D1

F

1

3

2

1

3

2

Size

A

B

C

D

D1

E

F

G

H

9.5±0.3

4.0±0.3

2.0±0.3

8.0±0.3

4.0±1.0

2.2±0.3

1.2±0.2

PHYSICAL DIMENSIONS
