TERMINATION
SPECIFICATION SHEET
JFW MODEL 50T-059
JFW Industries, Inc.
Phone:
317-887-1340
sales@jfwindustries.com
www.jfwindustries.com
Frequency Range
DC-1200 MHz
Impedance
50 Ohms nominal (± 1% At DC)
VSWR
1.06:1 maximum
DC-250 MHz
1.1:1 maximum
250-500 MHz
1.2:1 maximum
500-1200 MHz
RF Input Power
30 Watts average @ 25ºC
Peak Power
3000 Watts (1 microsecond)
RF Connector
TNC female
Operating Temperature Range
-55ºC to +85ºC
Physical Size
See outline drawing 092-725
10/16/1997
ECR/ECN #
DATE
REV
APPR / DATE
ECR/ECN #
DATE
REV
APPR / DATE
9999
02/13/2003
A
SL 03/04/2003
JFW FORM E-7-F REV F
Page 1 of 1
