X24C01A

11

NOTE:

1. ALL DIMENSIONS IN INCHES (IN PARENTHESES IN MILLIMETERS)

2. PACKAGE DIMENSIONS EXCLUDE MOLDING FLASH

0.020 (0.51)

0.016 (0.41)

0.150 (3.81)

0.125 (3.18)

0.110 (2.79)

0.090 (2.29)

0.430 (10.92)

0.360 (9.14)

0.300

(7.62) REF.

PIN 1 INDEX

0.145 (3.68)

0.128 (3.25)

0.025 (0.64)

0.015 (0.38)

PIN 1

SEATING

PLANE

0.065 (1.65)

0.045 (1.14)

0.260 (6.60)

0.240 (6.10)

0.060 (1.52)

0.020 (0.51)

TYP. 0.010 (0.25)

0

°

15

°

8-LEAD PLASTIC DUAL IN-LINE PACKAGE TYPE P

HALF SHOULDER WIDTH ON

ALL END PINS OPTIONAL

0.015 (0.38)

MAX.

0.325 (8.25)

0.300 (7.62)

PACKAGING INFORMATION
