M95320, M95320-W, M95320-R
Signal description
Doc ID 5711 Rev 12
9/44
2.6
Write Protect (W)
The main purpose of this input signal is to freeze the size of the area of memory that is
protected against Write instructions (as specified by the values in the BP1 and BP0 bits of
the Status Register).
This pin must be driven either high or low, and must be stable during all write operations.
2.7
VSS ground
VSS is the reference for the VCC supply voltage.
2.8
VCC supply voltage
Refer to Section 4.1: Supply voltage (VCC) on page 12.
