5 / 8 page

D I M E N S I O N A L

S P E C I F I C A T I O N S

I N C H E S

( M M )

B40-HF30 and B40-PF30

B40-PB60 and B40-HB60

20.88 (530)

8.18 (208)

4.15

(105)

5.56

(141)

Rotation Clearance

Rising Level

0.50 (13)

Falling Level

0.50 (13)

8.00 (203)

7.19

(182)

Plug

4.15

(105)

1" Sockolet

3.87 (98)

Electrical

Connection

5.93

(150)

8.46

(214)

10.12

(257)

20.88 (530)

8.18 (208)

3.90

(99)

5.56

(141)

Rotation Clearance

Rising Level

0.50 (13)

Falling Level

0.50 (13)

8.00 (203)

7.19

(182)

Plug

3.90

(99)

1" Schedule 80 Weldolet

3.87 (98)

Electrical

Connection

5.93

(150)

8.46

(214)

10.12

(257)

NOTES:

1. Allow 8 inches (203 mm) overhead clearance for cover removal.

2. Maximum ambient temperature at switch head should not

exceed +140° F (+60° C).
