PAM20ST6305

SOT-563 PACKAGE INFORMATION

OUTLINE DIMENSIONS

DIM

MILLIMETERS

INCHES

MIN

MAX

MIN

MAX

A

1.50

1.70

0.059

0.067

B

1.10

1.30

0.043

0.051

C

0.50

0.60

0.020

0.024

D

0.17

0.27

0.007

0.011

G

0.50 BSC

0.020 BSC

J

0.08

0.18

0.003

0.007

K

0.10

0.30

0.004

0.012

S

1.50

1.70

0.059

0.067

NOTES

1. Controlling dimension: inches.

2. Dimensioning and tolerances per ANSI Y14.5M, 1985.

3. Dimensions are exclusive of mold flash and metal burrs.

PAD LAYOUT DIMENSIONS

DIM

MILLIMETERS

INCHES

NOMINAL

NOMINAL

A

1.40

0.055

B

1.02

0.040

C

0.30

0.012

D

0.51

0.020

E

0.51

0.020

NOTES

1. Controlling dimension: inches.

A

B

D

G

J

C

K

S

1

A

B

D

C

E
