ASF250 datasheet(2/5 Pages) ASB

2 / 5 page

2/5

ASB Inc. · sales@asb.co.kr · Tel: +82-42-528-7223

October 2012

ASF250

5-1000 MHz MMIC Amplifier

Pin No.

Function

RF IN

GND

RF OUT / Bias

Mounting Recommendation (in mm)

Outline Drawing

Note: 1. The number and size of ground via holes in

a circuit board is critical for thermal and RF

grounding considerations.

2. We recommend that the ground via holes

be placed on the bottom of the lead pin 2

and exposed pad of the device for better RF

and thermal performance, as shown in the

drawing at the left side.

ESD Classification

HBM

Class 1C

Voltage Level:1900 V

Class B

Voltage Level: 225V

CAUTION: ESD-sensitive device!

Moisture Sensitivity Level (MSL)

Level 3 at 260°C reflow

ESD Classification & Moisture Sensitivity Level

Symbols

Dimensions (In mm)

MIN

NOM

MAX

1.40

1.50

1.60

0.89

1.04

1.20

0.36

0.42

0.48

0.41

0.47

0.53

0.38

0.40

0.43

4.40

4.50

4.60

1.40

1.60

1.75

3.64

---

4.25

2.40

2.50

2.60

2.90

3.00

3.10

0.35

0.40

0.45

0.65

0.75

0.85

1.40

1.50

1.60

ASF250

Pxxxx

Lot No.

Part No.
